• Lamps, rear, stop/turn/backup (1-piece assembly) with license plate light
• Glass, solar absorbing, tinted
• Grille guard screen, insect protection (mounted behind grille)
• Antenna, fixed mast
• Spare tire delete (STD)
• Wheel, spare delete
• Front fender extension, painted body color
• Lamps, cargo area, cab mounted with switch on center switch bank
• Assist steps
• Tires, front 225/70R19.5G highway blackwall Pirelli Max Axle Load: 7,940 lb. (Requires (YEY) Tires, rear 225/70R19.5G highway blackwall Pirelli, Max Axle Load: 15,000 lb. or (YEZ) Tires, rear 225/70R19.5G traction blackwall Pirelli, Max Axle Load: 15,000 lb.) (STD)
• Lamps, Smoked Amber roof marker
• Headlamps, halogen projector-beam
• Fog lamps, front, halogen
• Paint, solid
• Work light circuit provides additional wire for utility light at end of frame
• Grille, chrome
• Tires, front 225/70R19.5G highway blackwall Pirelli Max Axle Load: 7,940 lb. (STD)
• Bumper, front chrome
• Door handles, outside, chrome
• Provision for cab roof-mounted lamp/beacon provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
• Wheels, 19.5" x 6.75", 4-aluminum wheels, 8-holes, hub piloted Dura-Bright finish is on the outside of the wheel
• Auxiliary harness, 3' for headlamps and turn signals
• Tires, rear 225/70R19.5G traction blackwall Pirelli Max Axle Load: 15,000 lb.
• Grille guard screen, stone protection (mounted to bumper)
• Summit White
• Oil seal for front hub, Chicago Rawhide Nitrile for oil lubricated wheel bearings
• License plate kit, front
• Electrical Provisions, rear of frame, upfitter, body builder wiring includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn
• Paint Scheme, Style 1
• Spare tire delete (STD)
• Mirrors, outside, black, heated power-adjustable, high-visibility vertical camper-style, and lower convex spotter glass, manual-folding. Convex glass is not heated and not power adjustable. 102", Wide Load
• Oil filled front hubs, synthetic oil EmGard FE-75W-90

• Visors, driver and front passenger, vinyl
• Seat trim, Vinyl
• Speedometer, miles/kilometers
• Interior trim, Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
• Cruise control, steering wheel-mounted
• Door locks, power
• Air conditioning, single-zone
• Assist handle, front passenger and driver on A-pillars
• Floor covering, Graphite-colored rubberized-vinyl
• Steering wheel, urethane
• Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
• Steering column, manual Tilt-Wheel
• Driver Information Center, 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information (Included and only available with (IO3) Audio System with 4.2" diagonal color display or (IOR) Chevrolet Infotainment System with 7" diagonal color touch-screen.)
• Mirror, inside rearview manual day/night
• Seat Belt, Black
• Dark Ash seats with Jet Black interior accents, Vinyl seat trim
• Back-up alarm calibration This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting
• Power outlet, 110-volt AC
• Key system, 2 spare keys
• Seats, front 40/20/40 split-bench, cloth or vinyl 3-passenger. Includes driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Also includes manually adjustable driver lumbar and storage pockets. Includes (AG1) 10-way power seat.)
• Label, fasten seat belts "Fasten Seat Belts" reminder label on right hand and left hand front side door glass
• Remote Keyless Entry
• Seat adjuster, driver 10-way power
• Windows, power with driver express up and down and express down on all other windows

• Emissions, 50 state certification
• Brakes, hydraulic, heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
• Axle, Open rear axle, non-locking rear
• Capped Fuel Fill
• Steering, power (Bosch S2 8014 Plus)
• Fuel tank, rear only, 40 gallon mounted between frame side rails and behind rear axle
• Emissions, USA 50 State certified
• Rear wheel drive
• Incomplete vehicle
• Fuel, diesel B20
• Axle lubricant, rear, synthetic oil EmGard FE -75W-90
• Rear axle, 4.10 ratio Max road speed: 79 MPH
• Shock Absorbers, rear (Included with (FTC) 6,250 lb. front axle.)
• Trailering provisions, trailering wire harness only, trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
• Batteries, heavy-duty dual 1100 cold-cranking amps includes battery box mounted to left side under cab
• Exhaust brake
• Trailer brake controller, integrated
• Front suspension, 8,000 lb. (3,629 kg) multi-leaf, includes shock absorbers
• Rear axle, 4.10 ratio Max road speed: 79 MPH
• DPF, diesel particulate filter, manual regeneration customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
• Axle to End of Frame, 63"
• Wheelbase, 201" (510.5 cm), 120" CA
• Battery, top post threaded, battery jump start stud (located on battery box)
• Axle, limited slip, Dana Spicer Truetrac, torque proportioning limited slip
• Shock Absorbers, rear
• 30,000 lb. GCWR (13,607 kg)
• GVWR, 22,940 lb. (10,405 kg)
• Rear suspension, 15,500 lb. (7,031 kg) multi-leaf, vari-rate
• Rear axle, 15,000 lb. (6,804 kg) Dana Spicer S16-130, single reduction
• 6500 HD Series
• Exhaust system, straight, terminates ahead of rear wheels
• Front axle, 8,000 lb., Dana/Spicer D800-N, "I"-beam, non-driving
• Alternator, 220 amps
• Recovery hooks, front, frame-mounted, black
• Front stabilizer bar

• Work Truck Preferred Equipment Group includes standard equipment
• Snow Plow Prep Package includes (UNL) auxiliary harness for headlamps and turn signals, (KW5) 220-amp alternator, forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon

• Label information, clean idle, door location

• Daytime Running Lamps, with automatic exterior lamp control

• Airbags, Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Rear Vision Camera, display integrated into Radio (Shipped loose in cab for upfitter installation.)
• OnStar, delete
• Airbag deactivation switch, frontal passenger-side (Included and only available with (AY0) airbags.)
• Horn, dual-note
• Backup alarm (Includes (SFW) SEO Calibration for backup alarm.

• StabiliTrak, Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
• Brake, parking, driveline park brake system
• Traction control

Snow Plow Prep Package

• DriveType
• DriveType: Rear Wheel Drive
• Fuel Economy
• City: 0
• Hwy: 0
• Combined: 0
• Fuel System
• Fuel System: Direct Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 65 gal
• Fuel Type
• Fuel Type: Diesel Fuel
• Horse Power
• Horse Power: 350
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
